| Models | Han 2023 EV Champion Edition 610KMFour wheel Drive Flagship |
| Guide price | 279800 |
| Basic parameters | |
| Manufacturer | BYD |
| level | Medium to large-sized vehicles |
| Energy types | Pure electric |
| Time to market | 2023.03 |
| CLTC pure electric range(km) | 610 |
| Fast charging time (hour) | 0.5 |
| Slow charging time (hour) | \ |
| Fast charging percentage | 80 |
| Maximum power (KW) | 380 |
| Maximum torque (N.m) | 700 |
| Motor (Ps) | 517 |
| Length * Width * Height(mm) | 4995*1910*1495 |
| Body structure | 4-door 5-seater sedan |
| Maximum speed (km/h) | 185 |
| Official 0- 100km/hacceleration (s) | 3.9 |
| Electricity equivalent fuel consumption | 1.69 |
| Body | |
| Length (mm) | 4995 |
| Width (mm) | 1910 |
| Height (mm) | 1495 |
| Wheelbase (mm) | 2920 |
| Front wheel base (mm) | 1640 |
| Rear wheel base (mm) | 1640 |
| approach angle | 13 |
| departure angle | 14 |
| Body structure | notchback |
| Number of doors (PCS) | 4 |
| Seats (number) | 5 |
| Trunk volume | \ |
| Preparation mass (kg) | 2250 |
| Maximum full load mass | 2625 |
| Motor | |
| The motor type | Permanent magnet/synchronous |
| Total motor power (kW) | 380 |
| Total torque of motor (N- M) |
700 |
| Maximum power of front motor (kW) |
180 |
| Maximum torque of front motor (N ·m) |
350 |
| Number of drive motor | Dual motor |
| Machine layout | Front+Rear |
| Battery type | lithium iron phosphate battery |
| CLTC pure electric range(km) | 610 |
| Battery energy (kWh) | 85.44 |
| Battery energy density (Wh/kg) | 150 |
| 100km power consumption(kWh/100km) | 14.9 |
| Quick charging time(hour) | 0.5 |
| Slow charging time(hour) | \ |
| Fast charging capacity(%) | 80 |
| Transmission | |
| Number of block | 1 |
| Transmission type | Fixed gear ratio gearbox |
| Referred to as" | Electric single-speed transmission |
| Chassis steering | |
| Drive way | Dual motor four-wheel drive |
| Front suspension type | MacPherson independent suspension |
| Front suspension type | Multi-link independent suspension |
| Power type | Electric power |
| Car body structure | frameless |
| Wheel brake | |
| Front brake type | Ventilated tray type |
| Rear brake type | disc |
| Parking brake type | Electronic parking |
| Front tyre specification | 245/45 R19 |
| Rear tyre specification | 245/45 R19 |
| Spare tire specifications | \ |
| Active/passive safety equipment | |
| Master/passenger-side airbags | Master●/passenger-side ● |
| Front/rear side airbags | Front●/Rear● |
| Front/rear head air bag (air curtain) | Front●/Rear● |
| knee airbag | ● |
| Passive pedestrian protection | ● |
| Tire pressure monitoring function | Tire Pressure Display |
| Run-flat tire | \ |
| Safety belt not fastened reminder | All vehicles |
| ISOFIX child seat interface | ● |
| ABS antilock | ● |
| Braking force distribution(EBD/CBC, etc.) | ● |
| Brake assist(EBA/BAS/BA etc.) | ● |
| Traction control(ASR/TCS/TRC etc.) | ● |
| Body stability control(ESC/ESP/DSC etc.) | ● |
| active safety | |
| Lane departure warning system | ● |
| Active brake/active safety system | ● |
| Fatigue driving warning | ● |
| DOW Open Door Alert | ● |
| Rear Collision Warning | ● |
| Rear Collision Warning | ● |
| Low Speed Warning | ● |
| Built-in car recorder | ● |
| Road rescue call | ● |
| Auxiliary/control configuration | |
| Driving mode switch | Movement economic Standard/comfort |
| Energy Recovery System | ● |
| Autohold | ● |
| Hill auxiliary | ● |
| Steep descent | \ |
| Variable suspension function Variable suspension function |
Suspension soft and hard adjustment |
| Driving hardware | |
| Front/Rear Parking Radar | Front●/Rear● |
| Driving assistance image | 360° panoramic image |
| Driving chassis/540° image | ● |
| Number of cameras | 5 |
| Number of ltrasonic radar | 12 |
| Number of millimeter wave radars | 5 |
| driving function | |
| cruise control | Full-speed adaptive cruise control |
| Assisted driving level | L2 |
| Reverse vehicle side warning system | ● |
| Satellite navigation system | ● |
| Navigation road condition information display | ● |
| Map Branding | Gaudet (name) |
| merging aid | ● |
| LKA | ● |
| Lane centering | ● |
| Road traffic signage recognition | ● |
| automatic parking | ● |
| remote control | ● |
| Automatic lane change assistance | ● |
| Steering wheel off hand detection | ● |
| Exterior/Anti-theft | |
| Rim Material | aluminum |
| Electric trunk | ● |
| Sensor Trunk | \ |
| Power trunk position memory | \ |
| Central locking in the car | ● |
| Key Type | Remote control key The bluetooth key NFC/RFID key" NFC/RFID |
| Keyless Start System | ● |
| Keyless entry function | front row |
| Concealed power door handles | ● |
| Active Closed Grille | ● |
| Remote start function | ● |
| Battery preheating | ● |
| external discharge | ● |
| Exterior lights | |
| Low beam light source | LED |
| High beam light source | LED |
| Lighting Features | \ |
| LED daytime running lights | ● |
| Adaptive high and low beam | ● |
| Automatic headlamps | ● |
| vehicleturn indicator light | ● |
| Headlight rain and fog mode | ● |
| Height adjustable headlamps | ● |
| Headlight washers | \ |
| Delayed headlight off | ● |
| Sunroof/Glass | |
| Sunroof type | Openable panoramic sunroof |
| Front/rear power windows | Front●/Rear● |
| One-touch window up/down function | homologation |
| Anti-window pinch function | ● |
| Multi-layer acoustic glass | front row |
| Rear windshield shade | \ |
| Rear side privacy glass | ● |
| Car Cosmetic Mirror | Master driver + light Co-pilot + light |
| rear wiper | \ |
| Sensor wiper function | Rainfall sensing type |
| rearview mirror | |
| Exterior Mirror Function | Electric adjustment Electric Folding Mirror memory Mirror heating Automatic reverse flip Lock Auto Fold |
| Screen/System | |
| Center color screen | Touch LCD |
| Center screen size | 15.6 |
| large rotating screen | ● |
| Bluetooth/Car Phone | ● |
| Cell phone connectivity/mapping | HiCar |
| Voice Recognition Control System | multimedia system navigator telephones refrigeration skylight |
| In-vehicle Intelligent System | DiLink |
| Intelligent Configuration | |
| Telematics | ● |
| 4G/5G | 4G 5G |
| OTA upgrade | ● |
| wi-fi | ● |
| Mobile APP Remote Function | Door Controls Window control Start the vehicle. Charge Management Air conditioning control vehicle location |
| Steering Wheel/Inner Mirror | |
| Steering wheel material | dermis |
| Steering wheel position adjustment | Electric up and down+fore and aft adjustment |
| Gear Shift Form | Electronic Gear Shift |
| multifunction steering wheel | ● |
| Heated steering wheel | ● |
| Steering wheel memory | ● |
| Car computer display screen | colorful |
| Full LCD instrument cluster | ● |
| Liquid crystal instrument size | 12.3 |
| HUD head-up digital display | ● |
| Inside Rearview Mirror Function | Automatic anti-dazzle |
| In-vehicle charging | |
| Multimedia/Charging Interface | USB SD |
| Number of interfaces | 4 front/2 rear |
| 220V/230V power supply | ● |
| Mobile wireless charging function | front row |
| Seat Configuration | |
| Seat Material | dermis |
| Sport seats | ● |
| Main seat adjustment | Adjustment Back -up adjustment High and low adjustment (4-way) Lumbar support (4-way) |
| Adjustment of passenger seat | Adjustment Back -up adjustment High and low adjustment (2-way) Lumbar support (4-way) |
| Power adjustable main/passenger seat | Master●/passenger-side ● |
| Front Seat Function | ●heater ●ventilate |
| Power seat memory function | Driving position |
| Passenger seat rear adjustable buttons | ● |
| Second row seat adjustment | Back -up adjustment |
| Power adjustable second row seats | ● |
| Second row seat function | ●heater ●ventilate |
| Rear Seat Dismounting Form | \ |
| Front/rear center armrest | Front●/Rear● |
| Rear Cup Holder | ● |
| Audio/In-Car Lighting | |
| Loudspeaker Brands | Dynaudio |
| Number of speakers | 12 |
| Touch Reading Lamp | ● |
| Interior ambient lighting | polychrome |
| Air conditioners/refrigerators | |
| Air conditioning temperature control method | automatic air conditioning |
| heat pump air conditioner | ● |
| Individual rear air-conditioning | |
| Rear seat air vents | ● |
| Temperature zone control | ● |
| Car Air Purifier | ● |
| In-vehicle PM2.2 filters | ● |
| Negative Ion Generator | ● |
| In-car scenting devices | ● |
| Note: 1,"●" indicates that there is this configuration, "o" means optional, "\" means that there is no such configuration; 2, The above parameter configuration is for reference only, the specific information is subject to the actual vehicle; |
|
