| Models | VOYAH FREE 2024 Ultra Long Range Intelligent Driving Edition |
| Guide price | 266900 |
| Basic parameters | |
| Manufacturer | VOYAH Car |
| Level | Medium and large SUV |
| Energy types | Add-ons |
| Time to market | 2023.08 |
| WLTC pure electric range（km） | 160 |
| CLTC pure electric range (km) | 210 |
| Fast charging time (hour) | 0.43 |
| Slow charging time (hour) | 5.7 |
| Fast charging percentage | 30-80 |
| Maximum power (KW) | 360 |
| Maximum torque (N.m) | 720 |
| Engine | 1.5T 150PS L4 |
| Motor (Ps) | 490 |
| Length * Width * Height (mm) | 4905*1950*1645 |
| Body structure | 5-door, 5-seat SUV |
| Maximum speed (km/h) | 200 |
| Official 0-100km/h acceleration (s) | 4.8 |
| Fuel consumption under minimum state of charge (L/100km) | 6.69 |
| Body | |
| Length (mm) | 4905 |
| Width (mm) | 1950 |
| Height (mm) | 1645 |
| Wheelbase (mm) | 2960 |
| Front wheel base (mm) | 1654 |
| Rear wheel base (mm) | 1647 |
| Minimum ground clearance (mm) | 113 |
| Approach Angle（°） | 18 |
| Departure Angle（°） | 25 |
| Body structure | SUV |
| Number of doors (PCS) | 5 |
| Seats (number) | 5 |
| Tank volume (L) | 56 |
| Trunk volume (L) | 560-1320 |
| Preparation mass (kg) | 2270 |
| Maximum full load mass (kg) | 2655 |
| Engine | |
| Engine Model | DAM15NTDE |
| Displacement (ml) | 1499 |
| Intake form | Turbocharged |
| Engine Layout | horizontal position |
| Cylinder arrangement | L |
| Number of cylinders | 4 |
| Valve structure | DOHC |
| Maximum horsepower（Ps） | 150 |
| Maximum horsepower speed（rpm） | 5500 |
| Maximum torque（N·m） | 220 |
| Maximum torque speed（rpm） | 2500-4000 |
| Motor | |
| The motor type | Permanent magnet/synchronous |
| Total motor power (kW) | 360 |
| Total torque of motor (N-M) | 720 |
| Maximum power of front motor (kW) | 160 |
| Maximum torque of front motor (N·m) | 310 |
| Maximum power of rear motor (kW) | 200 |
| Maximum torque of rear motor (N·m) | 410 |
| Drive motor number | Dual motor |
| Machine layout | Front + Rear |
| The battery type | Nickel-cobalt-manganese battery |
| Battery cooling method | Liquid cooling |
| CLTC pure electric range (km) | 210 |
| Battery energy (kWh) | 39.2 |
| 100km power consumption (kWh/100km) | 21 |
| Quick charging time (hour) | 0.43 |
| Slow charging time (hour) | 5.7 |
| Fast charging capacity (%) | 30-80 |
| Transmission | |
| Number of block | 1 |
| Transmission type | Fixed gear ratio gearbox |
| Referred to as" | Electric single-speed transmission |
| Chassis steering | |
| Drive way | Dual motor 4WD |
| Front suspension type | Double-wishbone independent suspension |
| Front suspension type | Multi-link independent suspension |
| Power type | Electric assist |
| Car body structure | load bearing |
| Wheel brake | |
| Front brake type | ventilated disc |
| Rear brake type | ventilated disc |
| Parking brake type | Electronic Parking |
| Front tyre specification | 255/45 R20 |
| Rear tyre specification | 255/45 R20 |
| Active/passive safety equipment | |
| Master/passenger-side airbags | Master●/passenger-side● |
| Front/rear side airbags | Front●/Rear |
| Front/rear head air bag (air curtain) | Front●/Rear● |
| Tire pressure monitoring function | Tire pressure display |
| Safety belt not fastened reminder | Front row |
| ISOFIX child seat interface | ● |
| ABS antilock | ● |
| Braking force distribution (EBD/CBC, etc.) | ● |
| Brake assist (EBA/BAS/BA etc.) | ● |
| Traction control (ASR/TCS/TRC etc.) | ● |
| Body stability control (ESC/ESP/DSC etc.) | ● |
| Lane departure warning system | ● |
| Active brake/active safety system | ● |
| Fatigue driving warning | ● |
| Door opening warning | ● |
| Forward Collision Warning | ● |
| Rear Collision Warning | ● |
| Sentinel mode/clairvoyance | ● |
| Low Speed Warning | ● |
| Built-in car recorder | ● |
| Auxiliary/control configuration | |
| Driving mode switch | Movement Economy Standard/Comfort Snow Cross Country |
| Energy Recovery System | ● |
| Autohold | ● |
| Hill auxiliary | ● |
| Steep descent | ● |
| Variable suspension function | ●Suspension height adjustment |
| Air suspension | ● |
| Driving hardware | |
| Front/rear parking radar | Front●/rear● |
| Driving assistance image | 360° panoramic image |
| Transparent chassis/540° image | ● |
| Number of cameras | 10 |
| Number of ultrasonic radars | 12 |
| Number of millimeter-wave radars | 5 |
| driving function | |
| cruise control | Full-speed adaptive cruise control |
| Driver assistance class | L2 |
| Reverse vehicle side warning system | ● |
| Satellite navigation system | ● |
| Navigation road condition information display | ● |
| Map Branding | Baidu |
| High Precision Maps | ● |
| merging aid | ● |
| lane keeping assist system | ● |
| Road traffic signage recognition | ● |
| automatic parking | ● |
| Start reminder | ● |
| External/anti-theft configuration | |
| Rim Material | Aluminum alloy |
| Roof rack | ● |
| Side sliding door form | Bilateral electric |
| Electric trunk | ● |
| Induction trunk | ● |
| Electric trunk position memory | ● |
| electronic immobilizer | ● |
| Car central lock | ● |
| Key Type | Remote control key The bluetooth key |
| Keyless boot system | ● |
| Keyless entry function | Full car |
| Hide electric door handles | ● |
| Remote start function | ● |
| Battery preheating | ● |
| external discharge | ● |
| Light configuration | |
| Dipped light source | LED |
| High beam light source | LED |
| Lighting Features | matrix |
| LED daytime running lights | ● |
| Adaptive high and low beam | ● |
| Automatic headlamps | ● |
| Steering auxiliary light | ● |
| Headlamp height adjustable | ● |
| Delay off of headlights | ● |
| Glass/rearview mirror | |
| Sunroof type | Panoramic skylight can be opened |
| Front/rear electric Windows | Front●/rear● |
| Window lifting with one button function | whole car |
| Windows against hand pinch function | ● |
| Multilayer soundproof glass | Front Row |
| Rear side privacy glass | ● |
| Cosmetic mirror in car | Master driver + light Co-pilot + light |
| Rear window wiper | ● |
| Induction wiper function | Rainfall Sensing Type |
| rearview mirror | |
| Exterior Mirror Function | Electric adjustment Electric Folding Rearview Mirror Memory Heated rearview mirror Reverse auto roll down Automatic folding of locked cars Automatic anti-dazzle |
| Multimedia Configuration | |
| Centrally controlled color screen | Touch LCD screen |
| Central control screen size | 12.3 inches |
| Passenger side entertainment screen | 12.3 inches |
| Center control LCD split-screen display | ● |
| Bluetooth/Car phone | ● |
| Mobile Internet | ●HICAR support |
| Speech recognition control system | Multimedia System Navigation Phone |
| gesture | ● |
| Facial recognition | ● |
| voice recognition | \ |
| CarIntelligent chip | Qualcomm Snapdragon 8155 |
| Rear LCD screen | ● |
| Rear LCD screen size | ● |
| Multimedia system memory capacity（GB） | 16 |
| Storage capacity of the multimedia system（GB） | 128 |
| Intelligent Configuration | |
| Internet of Vehicles | ● |
| 4G/5G | 5G |
| OTA upgrade | ● |
| In-vehicle biomonitoring systems | ● |
| Mobile APP Remote Function | Door Controls Start the vehicle. Charge Management Air conditioning control vehicle location Car owner service Scheduled maintenance |
| Active noise reduction | ● |
| Steering Wheel/Inner Mirror | |
| Steering wheel materia | cortex |
| Steering wheel position adjustment | Manual up and down + front and back adjustment |
| multifunction steering wheel | ● |
| Steering wheel shift | \ |
| Steering wheel heating | \ |
| Steering wheel memory | \ |
| Driving computer display screen | colorful |
| Full LCD dashboard | ● |
| LCD instrument dimensions | 12.3 inches |
| Inside Rearview Mirror Function | Automatic anti-dazzle |
| In-vehicle charging | |
| Multimedia charging port | USB Type-c |
| Number of USB/ Type-c ports | ●2 in the front row/2 in the back |
| Mobile phone wireless charging function | Front row |
| Baggage compartment 12V power por | ● |
| Seat Configuration | |
| Seat Material | Leather/suede mix and match |
| Master seat adjustment mode | Front and rear adjustment Backrest adjustment High and low adjustment (4-way) Lumbar support (4-way) adjustment |
| Passenger seat adjustment mode | Front and rear adjustment Backrest adjustment High and low adjustment (4-way) Lumbar support (4-way) adjustment |
| Master/passenger seat electric adjustment | Main●/passenger ● |
| Front Seat Function | ●heater ●ventilate ●massage |
| Electric seat memory function | ●driver's seat |
| Rear seat reclining form | ●Scale down |
| Front/rear center handrail | Front ●/rear● |
| Rear Cup Holder | ● |
| Audio/In-Car Lighting | |
| Loudspeaker brand name | ●Dynaudio |
| Number of speakers | 10 |
| Interior ambient lighting | 64 colors |
| Air conditioners/refrigerators | |
| Air conditioning temperature control method | The automatic air conditioning |
| Rear independent air conditioner | \ |
| Rear air outlet | ● |
| Temperature zone control | ● |
| Car Air Purifier | ● |
| PM2.5 filter device in car | ● |
| Negative Ion Generator | ● |
| Car perfume device | ● |
| Note: 1,"●" indicates that there is this configuration, "o" means optional, "\" means that there is no such configuration; 2, The above parameter configuration is for reference only, the specific information is subject to the actual vehicle; |
|
